Machinery - Fillers - Process Plant Network

IOPAK Precision Rotary Valve Pneumatic Piston Filler P4-2R34

Plunger Diameter: 54 mm Stroke: 50.8 mm Fill Volume Range: 0 - 116 mL Cycle Rate: 0 - 120 cycles/min Air Consumption: 85 L/min Optional Items: - Filling Nozzle - Product Hopper (with or without Lid)

IOPAK Benchtop Peristaltic Pump Filler F6-12L

HONEY, OIL SAUCE, SOUP & COSMETIC MANUFACTURERS - BAKERS TOO - THIS FILLER IS FOR YOU! The IOPAK Pumpfill bench top peristaltic pump liquid filler is an excellent introduction to production for the smaller manufacturer. - It is VERY reasonably priced - It is reliable, accurate and simple to operate. <Applications> Honey producers and oil producers, sauce manufacturers, bakers - can all use th

IOPAK Servo Driven Auger Filler on Mobile Frame AF-450

<Applications> Designed for micro molecules or powder, (applications vary widely in the food industry) for products such as milk powder, glucose powder, albumen, coffee, rice powder and seasonings etc. <Specifications> Model No.: AF-450 Accuracy: +/- 0.3 to 1 % approx. (Product & Fill Volume Dependent) Speed: Product Dependent Servo Motor: 2,000 W - Panasonic Hopper Size: 50 L (Split Hopper) with

IOPAK Bucket Filling System

This system consists of the filling station and the lid-pressing station. Operator to manually place the lids onto the buckets. We design, engineer and build this system entirely in Australia. It is a full washdown system rated IP65 and uses Masosine pumps as filling and CIP. Can fill 6x 20Kg buckets and 8x 10Kg buckets. The system can be custom-designed to suit your requirements - please consu

IOPAK Servo Driven Auger Filler with Loadcells SAF-550W

Youtube Link: http://youtu.be/dmVilcz0kQ8 http://youtu.be/BMJz3L9ePl0 <Applications> Designed for micro molecules or powder, (applications vary widely in the food industry) for products such as milk powder, glucose powder, albumen, coffee, rice powder and seasonings etc. <Specifications> Model No.: SAF-550 Fill Range: Max 5,000 gms Accuracy: +/- 0.3 â€“ 1 % (Product & Fill Volume Dep

IOPAK Servo Driven Auger Filler with Weight Feedback System SPF-200W

<Specifications> Max Weight: 5,000 gms Accuracy: +/- 0.3 - 1 % Agitating Motor: 0.55 kW Hopper Capacity: 50 Ltr Power Supply: 1-Phase, 240V, 50Hz Included Accessories: - One Size Auger Tooling - One Size Bottle Feeding Screw - Weight Feedback and Reject

IOPAK 4 Head Liquid Filling System NPCR-4

Please let us know the bottle size, cap size, product, label and speed required? From there we can quote you a bespoke system.

IOPAK Single Head Weigh Filler WEIGHFILL

Youtube Link: http://youtu.be/8itus6ooXFY

IOPAK Servo Driven Auger Filler SAF-450

Youtube Link: http://youtu.be/dmVilcz0kQ8 http://youtu.be/BMJz3L9ePl0 <Applications> Designed for micro molecules or powder, (applications vary widely in the food industry) for products such as milk powder, glucose powder, albumen, coffee, rice powder and seasonings etc. <Specifications> Model No.: SAF-450 Fill Range: Max 2,000 gms Accuracy: +/- 0.3 to 1 % approx. (Product & Fill Vol

IOPAK Servo Driven Auger Filler SAF-350

Applications: Designed for micro molecules or powder, (applications vary widely in the food industry) for products such as milk powder, glucose powder, albumen, coffee, rice powder and seasonings etc. <Specifications> Fill Range: Max 1,000grams, Minimum 100grams Accuracy: +/- 0.3 to 1 % (Product & Fill Volume Dependent) Speed: Product Dependent Hopper Size: 25 L Material Constructions:

IOPAK Servo Driven Twin Auger Filler TAF-200

<Specifications> Fill Range: Max 5,000 gms Capacity (High Speed Mode): Max 120 bottles/min Capacity (High Accuracy Mode): Max 60 bottles/min Fill Accuracy (High Speed Mode): +/- 0.3-1 gms Fill Accuracy (High Accuracy Mode): +/- 1-2 gms * Product, Fill Volume & Fill Speed Dependent Bottle Types: Tin, Glass, Plastic, Paper, etc Bottle Size: 50 - 200 Diameter x 80 - 270 H mm Power Supply

IOPAK Rotary Valve Piston Filler (Pneumatic Type) GCGBL 1000 HRP

This new IOPAK stand alone piston filler is fitted with a rotary valve and is suitable for sauces, yogurt, pastes as well as viscous creams. DETAILS OF MODEL GCGBL 1000 HRP Filling Range: 100 - 1000ml (1 litres) Accuracy: + -1% Air Consumption: TBC Capacity : TBC (Product dependant) <FEATURES> Rotary valve on fill head Positive shut-off nozzle (eliminating dripping) Stroke limitati

IOPAK Rotary Valve Piston Filler (Pneumatic Type) GCGBL 5000 HRP

This new IOPAK stand alone piston filler is fitted with a rotary valve and is suitable for sauces, yogurt, pastes as well as viscous creams. DETAILS OF MODEL GCGBL 5000 HRP Filling Range: 500 - 5,000ml (5 litres) Accuracy: + -1%. Air Consumption: 8.8ft ³/min Capacity : 6-8 cycles (Product dependant) Weight : 100Kgs FEATURES: Rotary valve on fill head Positive shut-off nozzle (elim

IOPAK Benchtop Semi Automatic Servo Driven Auger Filler SAF-300

* This mini sized machine is small enough to sit on a on a desktop! * Control System: It is PLC controlled and features a 5.7-inch colour touch screen interface. * The Metering screw is driven by a servo-motor which delivers the demand for high accuracy, high speed and greater stability * Choose between SUS316 or SUS304 stainless steel contacts parts as required * 20 recipes for future product

IOPAK Weighmetric Servo Driven Auger Filler (with Loadcell) SAF-450W

<Applications> Designed for micro molecules or powder, (applications vary widely in the food industry) for products such as milk powder, glucose powder, albumen, coffee, rice powder and seasonings etc. <Specifications> Model No.: SAF-450W Fill Range: Max 10,000 gms Accuracy: +/- 0.3 â€“ 1 % (Product & Fill Volume Dependent) Speed: Product Dependent Agitator Motor: 500 W Hopper Size: 50

IOPAK Weighmetric Servo Driven Auger Filler (with loadcell) AF-450

This brand new IOPAK Weighmetric Auger Filler is weight based. It is used where WEIGHT- not Volume is of paramount importance. It is fitted with a microprocessor based electronic controller which is load cell based. This IOPAK Auger filler is highly accurate. It does not rely only on the auger, as in most conventional fillers, but utilizes a load cell as well.The Auger filler is fitted with 3 s

IOPAK Horizontal Auger Filler HAF

Technical parameters: Dosing Range: 5g - 1,500 g (Change of Auger tooling required) Height: 580 - 600 mm Power requirement: 3-Phase, 415V, 50Hz Material: SUS304 Speed Control: Inverter Control (0.375kW and 0.55kW)

IOPAK Rotary Valve Piston Filler (Pneumatic Type) GCGA 500 HRP

This new IOPAK stand alone piston filler is fitted with a rotary valve and is suitable for sauces, yoghurt, pastes as well as viscous creams. DETAILS OF MODEL GCGA 500 HRP Filling Range: 30 - 500ml Filling Accuracy: + -0.5%. Capacity: 10-25 (pcs/m) (Product dependant) Air Supply: 95 (L/min) Net Weight: 50 Kg FEATURES The fully pneumatic fillers adopt the mechanical positioning syst

IOPAK Rotary Valve Piston Filler (Pneumatic Type) GCGA 250 HRP

This new IOPAK piston filler is fitted with a rotary valve and is suitable for sauces, yogurt, pastes as well as viscous creams. DETAILS OF MODEL GCGA 250 HRP Filling Range: 30 - 250ml Filling Accuracy: + -0.5%. Capacity: 10-25 (pcs/m) (Product dependant) Air Supply: 95 (L/min) Net Weight: 50 Kg FEATURES - The fully pneumatic fillers adopt the mechanical positioning system, and aff

IOPAK Gear Pump Filler (Benchtop) GPF-1000

This NEW IOPAK gear pump filler is suitable for free flowing liquid with temp of under 40 degrees C. Applications: Water, low viscosity, less sticky and non particle liquid filling such as syrup, perfume, creams lotions, shampoos, sauces etc. Features: - High filling accuracy by use of gear pump - Compact and mobile design - Easy to clean without disassembling whole unit - Ball valve sh

IOPAK Bag or Carton Bulk Weigh Filler (Dual Screw, All Stainless Steel) BW-10/50

EXCELLENT value for money on our fantastic new s/s IOPAK BW-10/50 Bag or Carton Weigh Filler [Range Of Applications]. - For Food, Medical, Pet food, chemical industry, etc - For fixed quantity packaging for powder & grains material Example: Milk powder, Seasoner, Bean products, Pet food, Metallic powder, Plastic grains & various Chemical materials. Specifications: Filling Type: Gravime

IOPAK Rotary Valve Piston Filler with Hopper GCGA 100 HR

The new IOPAK GCGA 100 HR bench mounted piston filler is suitable for liquids, pastes and creams such as cold cream, honey, fruit puree, etc. DETAILS OF MODEL GCGA 100 HR Filling Range: 10 - 100ml Air Supply Requirement: 3.5 Kgf/cmÃ‚Â² (50 PSI or 350 KPa) Air Consumption: 5.7ftÃ‚Â³/min Electric Supply: 240V AC single phase). FEATURES Rotary valve fitted on fill head Positive shut-off va

IOPAK Rotary Valve Piston Filler with Hopper GCGA 1000 HR

This new unit is suitable for liquids, pastes and creams such as cold cream, yogurt, soups, honey, fruit puree, etc. It has a fill range of approximately 250ml -1,000ml. Accuracy is +- 1%.The filling cycle is initiated by a foot operated pedal. It features an infeed hopper, rotary valve assembly, positive shut off valve, volume adjustment. It is designed for table top mounting and can also be

IOPAK Rotary Valve Pneumatic Piston Filler with Hopper GCGA 500 HR

This new unit is suitable for liquids, pastes and creams such as cold cream, yogurt, soups, honey, fruit puree, etc. It has a fill range of approximately 120ml - 500ml. Accuracy is +- 1%. The filling cycle is initiated by a foot operated pedal. It features an infeed hopper, rotary valve assembly, positive shut off valve, volume adjustment. It is designed for table top mounting and can also be use

IOPAK Rotary Valve Piston Filler with Hopper (Free Standing) GCGBL 5000 R

This new IOPAK stand alone piston filler is fitted with a rotary valve and is suitable for sauces, yogurt, pastes as well as viscous creams. DETAILS OF MODEL GCGBL 5000 R Filling Range: 500 - 5,000ml (5 litres) Accuracy: + -1%. Air Supply Requirement: 3.5 Kgf/cm (50 PSI or 350 KPa) Air Consumption: 5.7ftÃ‚Â³/min Electric Supply: 240V AC single phase). FEATURES Rotary valve on fill hea

IOPAK Poppet Valve Piston Filler GCA 250 P

The new IOPAK bench mounted piston filler is suitable for liquids as well as non viscous creams. This model GCA 250 P is designed for accurate filling of products in the 25g - 250ml range. The filling cycle is initiated by a foot operated pedal. It features poppet type head valving, positive shut-off valve, stroke limitation fill volume adjustment, and is designed for table top mounting. It ca

IOPAK Rotary Valve Piston Filler with Hopper (Free Standing) GCGBL 500 R

This new IOPAK stand alone piston filler is fitted with a rotary valve and is suitable for sauces, yogurt, pastes as well as viscous creams. DETAILS OF MODEL GCGBL 500 R Filling Range: 50 - 500ml Accuracy: + -1%. Air Supply Requirement: 3.5 Kgf/cmÃ‚Â² (50 PSI or 350 KPa) Air Consumption: 5.7ftÃ‚Â³/min Electric Supply: 240V AC single phase). FEATURES Rotary valve on fill head Positiv

IOPAK Poppet Valve Piston Filler GCA 500 P

This new IOPAK bench mounted piston filler is suitable for liquids as well as non-viscous creams. DETAILS OF MODEL GCA 500 P Filling Range: 50 - 500ml Accuracy: + -1%. Air Supply Requirement: 3.5 Kgf/cmÃ‚Â² (50 PSI or 350 KPa) Air Consumption: 5.7ftÃ‚Â³/min Electric Supply: 240V AC single phase). FEATURES Poppet valve on fill head Positive shut-off valve Stroke limitation fill volum

IOPAK Rotary Valve Piston Filler with Hopper (Free Standing) GCGBL 1000 R

This new IOPAK stand alone piston filler is fitted with a rotary valve and is suitable for sauces, yogurt, pastes as well as viscous creams. DETAILS OF MODEL GCGBL 1000 HR Filling Range: 100 - 1,000ml Accuracy: + -1%. Air Supply Requirement: 3.5 Kg/cubic cm (50 PSI or 350 KPa) Air Consumption: 5.7 cubic feet/min Electric Supply: 240V AC single phase). FEATURES Rotary valve on fil

IOPAK Poppet Valve Piston Filler GCA 1000 P

The new IOPAK bench mounted piston filler is suitable for liquids as well as non- viscous creams. It has a wide filling range. DETAILS OF MODEL GCA 1000 P Filling Range: 100 - 1000ml. Air Supply Requirement: 3.5 Kgf/cmÃ‚Â² (50 PSI or 350 KPa) Air Consumption: 5.7ftÃ‚Â³/min Electric Supply: 240V AC single phase). FEATURES Poppet valve on fill head Positive shut-off valve Stroke limitation

IOPAK Rotary Valve Piston Filler with Hopper GCGA 250 HR

This new unit is suitable for liquids, pastes and creams such as cold cream, honey, fruit puree, etc. Accuracy is +- 1%. The filling cycle is initiated by a foot operated pedal. It features an infeed hopper with rotary head valving, positive shut off valve, stroke limitation fill volume adjustment, and is designed for table top mounting. Construction is of Stainless Steel and the control syste
